XC7VX690T-1FF1761C产品详细规格

规格书 Virtex-7 T/XT FPGA Datasheet

7 Series FPGAs Overview

文档 Additional Wafer Fabrication 16/Dec/2013

Zynq-7000 Datasheet Update 02/Jun/2014

的LAB / CLB数 54150

安装类型 Surface Mount

逻辑元件/单元数 693120

标准包装 1

供应商设备封装 1761-FCBGA (42.5x42.5)

RAM位总计 54190080

工作温度 0°C ~ 85°C

电压 - 电源 0.97 V ~ 1.03 V

I / O针脚数 850

封装/外壳 1761-BBGA, FCBGA

的输入/输出数 850

RoHS指令 Contains lead / RoHS non-compliant

XC7VX690T-1FF1761C系列产品

型号

厂家

产品描述

XC7VX690T-1FF1761I  FPGA 850 I/O 1761FCBGA

XC7VX690T-1FF1157C  FPGA 600 I/O 1157FCBGA

XC7VX690T-1FF1157I  FPGA 600 I/O 1157FCBGA

XC7VX690T-1FF1158C  FPGA 350 I/O 1158FCBGA

XC7VX690T-1FF1158I  FPGA 350 I/O 1158FCBGA

XC7VX690T-1FF1926C  FPGA 720 I/O 1926BGA

XC7VX690T-1FF1926I  FPGA 720 I/O 1926BGA

XC7VX690T-1FF1927C  FPGA 600 I/O 1927BGA

XC7VX690T-1FF1927I  FPGA 600 I/O 1927BGA

XC7VX690T-1FF1930C  FPGA 1000 I/O 1930BGA

XC7VX690T-1FF1930I  FPGA 1000 I/O 1930BGA

XC7VX690T-1FFG1157C  FPGA 690K VIRTEX-7

XC7VX690T-1FFG1157I  FPGA 690K VIRTEX-7

XC7VX690T-1FFG1158C  FPGA 690K VIRTEX-7

XC7VX690T-1FFG1158I  FPGA 690K VIRTEX-7

XC7VX690T-1FFG1761C  FPGA 690K VIRTEX-7

XC7VX690T-1FFG1761I  FPGA 690K VIRTEX-7

XC7VX690T-1FFG1926C  FPGA 690K VIRTEX-7

XC7VX690T-1FFG1926I  FPGA 690K VIRTEX-7

XC7VX690T-1FFG1927C  FPGA 690K VIRTEX-7

XC7VX690T-1FF1158I

芯片详细信息

Manufacturer Part Number:

XC7VX690T-1FF1158I

Rohs Code:

 No

Part Life Cycle Code:

Active

Ihs Manufacturer:

XILINX INC

Reach Compliance Code:

not_compliant

HTS Code:

8542.39.00.01

Manufacturer:

Xilinx

Risk Rank:

5.87

Clock Frequency-Max:

1818 MHz

JESD-30 Code:

S-PBGA-B1156

Number of Inputs:

350

Number of Logic Cells:

693120

Number of Outputs:

350

Number of Terminals:

1156

Package Body Material:

PLASTIC/EPOXY

Package Code:

BGA

Package Equivalence Code:

BGA1156,34X34,40

Package Shape:

SQUARE

Package Style:

GRID ARRAY

Power Supplies:

1,1.8 V

Programmable Logic Type:

FIELD PROGRAMMABLE GATE ARRAY

Qualification Status:

Not Qualified

Subcategory:

Field Programmable Gate Arrays

Surface Mount:

YES

Technology:

CMOS

Terminal Form:

BALL

Terminal Pitch:

1 mm

Terminal Position:

BOTTOM
